• Source: https://community.nxp.com/t5/MPC5xxx/MPC5604P-bootloader/td-p/1906980
•

• We
• provide Rappid bootloader which can use either UART or CAN. It uses BAM serial boot mode. Notice that we do not provide source codes, it cannot be modified:
  提供 Rappid 引導程序，可使用 UART 或 CAN 介面。它採用 BAM 串列啟動模式。請注意，我們不提供原始碼，無法修改：
• https://www.nxp.com/webapp/Download?colCode=RAPPID_BOOTLOADER_UTILITY&appType=license
• If you are interested in flash resident bootloader, attached is a draft of application note (bootloader.zip).
  如果您對閃存駐留式引導程式感興趣，附件是套用筆記草稿 (bootloader.zip)。
• It’s written for MPC5634M, software is working. It can be used as a starting point to develop own solution for MPC560xB/P/S.
  該文件是為 MPC5634M 編寫的，軟體已投入運行。您可以將其作為開發 MPC560xB/P/S 解決方案的起點。
• Just in case, this is updated and published version for MPC57xx devices (software is written for MPC5748G):
  以防萬一，以下是針對 MPC57xx 裝置的更新和發布版本（軟體是為 MPC5748G 編寫的）：
  • http://www.nxp.com/assets/documents/data/en/application-notes/AN5319.pdf
  • http://www.nxp.com/assets/documents/data/en/application-notes-software/AN5319SW.zip
• Then I have CAN bootloader for MPC560xB/P/S – see please attached file bootloader_MPC560xBPS.zip. This is not official version, I’m not author, it’s provided AS IS with no support.
  然後我有適用於 MPC560xB/P/S 的 CAN 引導程式——請參閱附件 bootloader_MPC560xBPS.zip。這不是官方版本，我不是作者，它按原樣提供，不提供任何支援。
• And if you are looking for out of box solution, you can ask Vector (or other SW vendors) for help:
  如果您正在尋找開箱即用的解決方案，可以向 Vector（或其他軟體供應商）尋求協助：
• https://www.vector.com/int/en/products/products-a-z/embedded-software/flash-bootloader/
• Regards,
• Lukas
• bootloader_mpc560xbps.zip
• bootloader.zip

• lukaszadrapaNXP TechSupport @ NXP Community
  • https://community.nxp.com/t5/user/viewprofilepage/user-id/37795
